Ravello™
CUSTOMIZE YOUR SPA COLORS
Cabinets
parchment
ash
java
Shells
Arctic White
white-pearl
tuscan sun
Midnight Canyon
platinum
Description
- Seating: 3 Adults
- Dimensions: 7’ x 5'6" x 33"
- Jets: 39
- Water Care: FreshWater® IQ System Included
Features That Transform
Save Energy, Save Money
Every detail of your spa is designed for maximum efficiency. From the insulation and heater to the circulation pump and custom-fit spa cover, each component works in harmony to maintain your water’s warmth while keeping your energy costs low.
Ecotech® Plus Cabinet
Add a refined, contemporary touch to your spa. Featuring a sleek black header, elegant wood-grain detailing, stainless-steel accents, and a built-in LED light bar, this design enhances any outdoor setting with style and sophistication.
UltraMasseuse® System
Enjoy a personalized hydrotherapy experience with the UltraMasseuse® System. Choose from six distinct jet patterns and three adjustable speeds to craft a massage perfectly suited to your needs.
Hot Tub Essentials
Covers
Each spa includes a precision-crafted WeatherPro® cover designed specifically for your model. The snug fit ensures maximum heat retention and superior energy efficiency. Built for durability, every cover meets UL and ASTM safety standards and comes equipped with child safety locks for added peace of mind.
Cover Lifters
A cover lifter is the ideal companion for your spa, making it easy to remove and replace the cover on your own. This simple tool helps extend the life of your spa and cover while ensuring quick, effortless access—so you can relax in moments.
Steps
Color-coordinated steps provide both safety and convenience, helping you enter and exit your spa comfortably while matching your spa’s design perfectly.
Best Seat in the House
UltraMassage® Seat
The UltraMassage® Lounge soothes your neck, shoulders, full back, and calves, while Sole Soothers® jet clusters revitalize and stimulate your feet.
EcstaSeat®
Jets target large back muscles, while hip and wrist jets address often-overlooked stress points to help improve flexibility and range of motion.
Lumbarssage® seat
Specially designed jets relieve tension in the lumbar region, with calf jets providing lower-leg muscle relief.
Euphoria® Jet
Dual Euphoria® jets deliver a deep, penetrating massage to the thighs, knees, calves, and feet.
Looking for more information on this model?
Specifications
- Seating Capacity: 3 Adults
- Dimensions: 7′ x 5’6″ x 33″ / 213cm x 168cm x 84cm
- Water Capacity: 265 gallons / 1,025 liters
- Weight (Dry): 720 lbs. / 325 kg
- Weight (Filled): 3,460 lbs. / 1,590 kg
- Jet Count: 39 Total Jets
- Branding: Diagnostic Logo Light mounted in Spacer (between shell and cabinet)
- Bottom Seal: ABS Base Pan
- Insulating Cover: WeatherPro™ 4” tapered custom fit with hinge seal
- Spa Shell Options: Arctic White, White Pearl, Platinum, Tuscan Sun, or Midnight Canyon
- Cabinet Type: EcoTech® Plus
- Cabinet & Step Colors: Java, Ash & Parchment
- Cover Lifter: ProLift® III, or ProLift® II
- Cover Colors: Storm, Chestnut, Black
- Cover Design: Standard
- Speakers: 4 – 1.5” square
- Entertainment System: (Optional) Wireless Bluetooth® Audio System
- Step Type: (Optional) Utopia® Step in Java, Ash & Parchment
- Step Colors: Java, Ash & Parchment
- Smart Spa Technology: (Optional) Caldera Spas App, Powered by the Connected Spa Kit
- Jets: 1 Euphoria® jet, 2 OrbiSsage® jets, 4 VersaSsage® jets, 2 Euro-Pulse® jets, 30 Euro Directional jets
- Water Care Systems: FreshWater® IQ System Included
- Ultramasseuse System: N/A
- Jet Pumps: 2 ReliaFlo® Pumps; 1 Dual-Speed 2.5 HP (5.2 BHP) & 1 Single-Speed 2.5 HP (5.2 BHP)
- Control System: Advent® LCD Touchscreen 230v/50amp, 60Hz, Includes G.F.C.I. protected sub-panel
- Circulation Pump: EnergyPro® for quiet continuous filtration
- Heater Output: EnergyPro® Heater 4,000 Watts 230v
- Electrical Requirements: 230V / 50 amp
- GFCI Sub-panel: GFCI Sub-panel (50 amp) included
- Filter Size: 50 sq. ft. filter
- Ozone System: (Optional) Corona Discharge
- Water Feature: N/A
- Multi-color LED Lighting: SpaGlo® Multi-Zone LED Lighting including 7 Points-of-Interior Lights & Exterior Light Bar
- Energy Efficiency: Fully-insulated with FiberCor® material, 2 lb. density, CEC-compliant
Your Massage Your Way
Hot Tub Circuit Therapy
Flow through three seats in the Ravello, each designed to target muscles in your neck, back, hips, wrists, calves, and feet.
Liquid Just Got Smarter
FRESHWATER® IQ SYSTEM
Our advanced in-line water care system automatically monitors your spa water and provides easy on-screen guidance to keep it clean, clear, and naturally balanced.
